Description:
This shot-blasting machine using rolling path can continuously operate. It is a kind of automatic ball blasting device. This machine is mainly used in clearing the rust oxidized shin of H-beam, steel plate, steel pipeline. And it can smooth the beam surface and makes the steel easy to paint.
Our sand blasting machine can transports the work piece by trolley in double way, which makes the machine in the high efficiency. In addition, the sand blasting machine uses chromic steel plate that can protects the machine and can extent the using time.
Main Technical Parameter:

Model


HP0816

HP1018

HP1220

Dimension of Work-piece to be   Cleaned

Allowable passing section   (width×heigth)

800×1600mm

1000×1800mm

1200×2000mm

Length of workpiece

16000mm

16000mm

16000mm

Quality Standard

Clearness of surface


A-B Sa2-Sa2.5


Roughness of surface


15-20um


Production Efficiency(Travel Speed   of Workpiece

0.4-2.5m/min

0.4-2.5m/min

0.4-2.5m/min

Abrator

Model

Q034

Q034

Q034

Quantify

8

8

8

Abrator Capacity

8×250kg/min

8×250kg/min

8×250kg/min

Power

8×11kw

8×11kw

8×15kw

Circulation Capacity of Material   for Abrator

100t/h

110t/h

120t/h

Roller Path for Import/Output

Allowable Load

1000kg/m

1000kg/m

1000/kg/m

Conveying Speed

0.4-4m/min

0.4-4m/min

0.4-4m/min

Initiate Adding Quantity of   Material for Abrator

5000kg

6000kg

8000kg

Anti-dust System

Treated Wind Volume

16000m³/h

16000m³/h

16000m³/h

Power

15kw

15kw

22kw

Total Power


About140kw

About140kw

172kw
